SHORTSTAR SGW-60GN
- Product Specifications
- Download
- Product Catalog
| Product No. | SGW-60GN |
|---|---|
| Product Code | 61607 |
| Category | Low-Profile Heavy Duty |
| Stock | make to order |
| Swivel Caster/Fixed Caster | Swivel Caster |
| Wheel Type | GN |
| Product Number of Wheel | S-60GN |
| Type of Bracket | SGW Type |
| Material of Metal Fittings | Steel Plain |
| Material of mounting plate | Steel Plain |
| Color of Metal Fittings | Silver |
| Color of mounting plate | Silver |
| Body Coating | BZP(Brilliant Zinc Plating) |
| Body Bearing | Double Bearing |
| Stopper | Without |
| Material of Wheel | Grey Nylon |
| Material of Foil | Grey Nylon |
| Color of Wheel | Grey |
Wheel diameter(D[mm])？
 |
Φ60 |
Wheel Width(W[mm])？
 |
25 |
Boss Width[mm]？
 |
30 |
Wheel hole diameter[mm]？
 |
8.2 |
Mounting height(H[mm])？
 |
80 |
| Mounting Method | Plate Type |
Mounting base(A×B[mm])？
 |
70×54 |
Mounting dimensions(X×Y[mm])？
 |
54×36 |
Hole Diameter(P[mm])？
 |
6.5 |
Eccentricity(E[mm])？
 |
27 |
Turning Radius(R[mm])？
 |
58 |
Allowance Load(daN／kgf)※？
 |
130/132.6 |
| Wheel Weight[g] | 348 |
| Quantity per Case | 50 |
*Allowance load of one caster
Product catalog
Digital Catalog
Flyer
Other Resources
-
*The Picture is a typical product image.
You can download by click.
SGW-60GN
- Material of Wheel
- Usage
- Mounting Method
- Brand Logo
External dimensions
Wheel SpecificationIcon Description
Swivel Caster
Double Bearing
Plate Type
